¡ö CHARACTERISTICS
Closed Center - Non Reaction and Load Sensing Outlet, PVF* Priority Valve Connectiom: modulary mounting , Electrohydraulic control signal connection:guides the pressure signal of port A or B out of port EL,and then supplies the pressure signaI to the electricaI controI system£®
Comparison :
102S-5E-50 =HKUS50/5E
102S-5E-80 =HKUS80/5E
102S-5E-100 =HKUS100/5E
102S-5E-125 =HKUS125/5E
102S-5E-160 =HKUS160/5E
102S-5E-200 =HKUS200/5E
102S-5E-250 =HKUS250/5E
102S-5E-315 =HKUS315/5E
102S-5E-400 =HKUS400/5E
¡ö TECHNICAL DATA
|
TYPE
|
Displacement
|
Max. input speed
|
Max.input
|
Max.Cont.Back
|
Normal Input
|
Length
|
|
(ml/r)
|
(rpm)
|
Pressure (Mpa)
|
Pressure (Mpa)
|
Torque (N.m)
|
(mm)
|
|
102S-5E-50
|
50
|
100
|
16
|
2.5
|
<5
|
130
|
|
102S-5E-63
|
63
|
100
|
16
|
2.5
|
<5
|
132
|
|
102S-5E-80
|
80
|
100
|
16
|
2.5
|
<5
|
134
|
|
102S-5E-100
|
100
|
100
|
16
|
2.5
|
<5
|
137
|
|
102S-5E-125
|
125
|
100
|
16
|
2.5
|
<5
|
140
|
|
102S-5E-160
|
160
|
100
|
16
|
2.5
|
<5
|
145
|
|
102S-5E-200
|
200
|
100
|
16
|
2.5
|
<5
|
150
|
|
102S-5E-250
|
250
|
100
|
16
|
2.5
|
<5
|
156
|
|
102S-5E-280
|
280
|
75
|
16
|
2.5
|
<5
|
161
|
|
102S-5E-315
|
315
|
75
|
16
|
2.5
|
<5
|
166
|
|
102S-5E-400
|
400
|
75
|
16
|
2.5
|
<5
|
176
|
|
